Electro-voice ZXA1-90W


Electro-Voice engineers have raised the bar for portable sound once again, adding to the award-winning ZX loudspeaker family with the new ZXA1 – the self-powered version of the best-selling ZX1 compact two-way loudspeaker. ZXA1 is powered by an 800 watt amplifier module derived from EV’s world-tour-class Tour Grade series – amplifiers with audio quality and reliability proven at the very highest levels

Amplifier Power800 Watts (RMS)
Input ConnectionsXLR and TRS Combo; XLR with Independent Gain
Power Requirement120V: 95V – 132V, 50 – 60 Hz, 0.6A 230V:190V – 264V, 50 – 60 Hz, 0.4A
Speaker TypeFull-range, powered monitors, powered speakers, two-way, wedges
Frequency Response (-3 dB)60 – 20000 Hz Full Range Mode
Frequency Response (-10 dB)48 – 20000 Hz Full Range Mode
Recommended High-Pass Frequency36 Hz User Selectable
Max. SPL/1m (calc)126 dB
Coverage (Nominal -6 dB) H90 ° Rotatable
Coverage (Nominal -6 dB) V50 ° Rotatable
LF Transducer8-inch EV8L
HF Transducer1.25-inch DH2005
Crossover Frequency1800 Hz
Enclosure MaterialHigh Impact Polystyrene
GrillPolyester Powder Coated, 18GA Galvanized Steel
Height457 mm
Width282 mm
Depth264 mm
Weight Net8.62 kg
Additional information
Weight8.62 kg
Dimensions26.4 × 28.2 × 45.7 cm
