EV ZXA1
1,509.00₼
Electro-Voice engineers have raised the bar for portable sound once again, adding to the award-winning ZX loudspeaker family with the new ZXA1 – the self-powered version of the best-selling ZX1 compact two-way loudspeaker. ZXA1 is powered by an 800 watt amplifier module derived from EV’s world-tour-class Tour Grade series – amplifiers with audio quality and reliability proven at the very highest levels
Description
| Amplifier Power | 800 Watts (RMS) |
| Color | Black |
| Input Connections | XLR and TRS Combo; XLR with Independent Gain |
| Power Requirement | 120V: 95V – 132V, 50 – 60 Hz, 0.6A 230V:190V – 264V, 50 – 60 Hz, 0.4A |
| Speaker Type | Full-range, powered monitors, powered speakers, two-way, wedges |
| Frequency Response (-3 dB) | 60 – 20000 Hz Full Range Mode |
| Frequency Response (-10 dB) | 48 – 20000 Hz Full Range Mode |
| Recommended High-Pass Frequency | 36 Hz User Selectable |
| Max. SPL/1m (calc) | 126 dB |
| Coverage (Nominal -6 dB) H | 90 ° Rotatable |
| Coverage (Nominal -6 dB) V | 50 ° Rotatable |
| LF Transducer | 8-inch EV8L |
| HF Transducer | 1.25-inch DH2005 |
| Crossover Frequency | 1800 Hz |
| Enclosure Material | High Impact Polystyrene |
| Flying | No |
| Outdoor | No |
| Grill | Polyester Powder Coated, 18GA Galvanized Steel |
| Height | 457 mm |
| Width | 282 mm |
| Depth | 264 mm |
| Weight Net | 8.62 kg |
Additional information
| Weight | 8.62 kg |
|---|---|
| Dimensions | 26.4 × 28.2 × 45.7 cm |
